INTERRUPTOR DE NAVEGACIÓN (SWNA3)

General Specifications
Current Rating: 50mA
Voltage Rating: 12VDC
Dielectric Withstanding Voltage:250VAC for 1 minute
Contact Resistance: 100m Ohm Max.(initial)
Insulation Resistance: 100M Ohm Min.
Operating Force: 190gf ± 50gf
Total Travel: 0.2mm ± 0.1mm
Operating Life: 1,000,000 cycles Min.
Solder Specifications: 260 deg. for 3 seconds
Function Operating: SP3T
Temperature: -10 deg.~+60 deg.
modelo : SWNA3

General Specifications

Current Rating: 50mA

Voltage Rating: 12VDC

Dielectric Withstanding Voltage:250VAC for 1 minute

Contact Resistance: 100m Ohm Max.(initial)

Insulation Resistance: 100M Ohm Min.

Operating Force: 190gf ± 50gf

Total Travel: 0.2mm ± 0.1mm

Operating Life: 1,000,000 cycles Min.

Solder Specifications: 260 deg. for 3 seconds

Function Operating: SP3T

Temperature: -10 deg.~+60 deg.
