BALL ROLLING SWITCH_SRBS200112-03

Input Current (mA)

Operating Voltage (V)

Condition

1.0

5

--

1.

Contact Rating

10mA, 5VDC

2.

Contact Resistance

10Ω max.

3.

Operation Diagram

Refer to Fig. 1

4.

Insulation Resistance

1000MΩmin.,100VDC

5.

Dielectric Strength

500VDCmin.,1minute

6.

Capacitance

5pF max.

7.

Conductive Rate

98% min.

Test Item

                        Contents

1

Operating Temperature

-25°C~ 85°C

2

Storage Temperature

-40°C~ 85°C

3

Humidity

40 °C/ 95 %RH

4

Mechanical Life

2 Hz horizontal

1,000,000 times

5

Electrical Life

100,000 times
